KarmaGuiPlatformIO Struct Reference

Collaboration diagram for KarmaGuiPlatformIO:

Public Attributes
void(*	Platform_CreateWindow )(KarmaGuiViewport *vp)
void(*	Platform_DestroyWindow )(KarmaGuiViewport *vp)
void(*	Platform_ShowWindow )(KarmaGuiViewport *vp)
void(*	Platform_SetWindowPos )(KarmaGuiViewport *vp, KGVec2 pos)
KGVec2(*	Platform_GetWindowPos )(KarmaGuiViewport *vp)
void(*	Platform_SetWindowSize )(KarmaGuiViewport *vp, KGVec2 size)
KGVec2(*	Platform_GetWindowSize )(KarmaGuiViewport *vp)
void(*	Platform_SetWindowFocus )(KarmaGuiViewport *vp)
bool(*	Platform_GetWindowFocus )(KarmaGuiViewport *vp)
bool(*	Platform_GetWindowMinimized )(KarmaGuiViewport *vp)
void(*	Platform_SetWindowTitle )(KarmaGuiViewport *vp, const char *str)
void(*	Platform_SetWindowAlpha )(KarmaGuiViewport *vp, float alpha)
void(*	Platform_UpdateWindow )(KarmaGuiViewport *vp)
void(*	Platform_RenderWindow )(KarmaGuiViewport *vp, void *render_arg)
void(*	Platform_SwapBuffers )(KarmaGuiViewport *vp, void *render_arg)
float(*	Platform_GetWindowDpiScale )(KarmaGuiViewport *vp)
void(*	Platform_OnChangedViewport )(KarmaGuiViewport *vp)
int(*	Platform_CreateVkSurface )(KarmaGuiViewport *vp, KGU64 vk_inst, const void *vk_allocators, KGU64 *out_vk_surface)
void(*	Renderer_CreateWindow )(KarmaGuiViewport *vp)
void(*	Renderer_DestroyWindow )(KarmaGuiViewport *vp)
void(*	Renderer_SetWindowSize )(KarmaGuiViewport *vp, KGVec2 size)
	Resize swap chain, frame buffers etc. (called after Platform_SetWindowSize)
void(*	Renderer_RenderWindow )(KarmaGuiViewport *vp, void *render_arg)
	(Optional) Clear framebuffer, setup render target, then render the viewport->DrawData. 'render_arg' is the value passed to Karma::KarmaGui::RenderPlatformWindowsDefault
void(*	Renderer_SwapBuffers )(KarmaGuiViewport *vp, void *render_arg)
	(Optional) Call Present/SwapBuffers. 'render_arg' is the value passed to Karma::KarmaGui::RenderPlatformWindowsDefault.
KGVector< KarmaGuiPlatformMonitor >	Monitors
KGVector< KarmaGuiViewport * >	Viewports

Member Data Documentation

Renderer_RenderWindow

void(* KarmaGuiPlatformIO::Renderer_RenderWindow) (KarmaGuiViewport *vp, void *render_arg)

(Optional) Clear framebuffer, setup render target, then render the viewport->DrawData. 'render_arg' is the value passed to Karma::KarmaGui::RenderPlatformWindowsDefault

Parameters

vp	The viewport to be rendered
render_arg	The 'render_arg' is the value passed to Karma::KarmaGui::RenderPlatformWindowsDefault, usually void pointer is accepted in this case.

Since

Karma 1.0.0

Renderer_SetWindowSize

void(* KarmaGuiPlatformIO::Renderer_SetWindowSize) (KarmaGuiViewport *vp, KGVec2 size)

Resize swap chain, frame buffers etc. (called after Platform_SetWindowSize)

Since

Karma 1.0.0

Renderer_SwapBuffers

void(* KarmaGuiPlatformIO::Renderer_SwapBuffers) (KarmaGuiViewport *vp, void *render_arg)

(Optional) Call Present/SwapBuffers. 'render_arg' is the value passed to Karma::KarmaGui::RenderPlatformWindowsDefault.

Parameters

vp	The viewport to be rendered
render_arg	The 'render_arg' is the value passed to Karma::KarmaGui::RenderPlatformWindowsDefault, usually void pointer is accepted in this case.

Since

Karma 1.0.0

---

The documentation for this struct was generated from the following file:

• Karma/src/Karma/KarmaGui/KarmaGui.h
